Expanded polystyrene foam core is locally removed to provide one inch of minimum clearance at the reinforcing bar. The first two bar sets of the tilt-up panel vertical reinforcing are placed near the panel edge as shown, incorporating typical U-mesh reinforcement.
U-MESH, TYP. REMOVE EPS TO PROVIDE 1" MIN. CLEARANCE AT REBAR 2" 4" 1 1/2" PLACE FIRST TWO BAR SETS OF TIPS PANEL VERT. REINFORCING NEAR PANEL EDGE AS SHOWN
