A camera mount is installed directly to a light pole with weatherproof mounting hardware and a dedicated pathway within the mount footprint. Cables route downward within the interstitial space of the light pole from a light fixture above. One 1-1/4 inch underground conduit provides the incoming pathway at the base of the pole.
CAMERA MOUNT,INSTALLED DIRECTLY TO LIGHT POLE. PROVIDE PATHWAY WITHIN CAMERA MOUNT FOOTPRINT UPON LIGHT POLE. WEATHERPROOF PATHWAY AND MOUNTING HARDWARE. TO LIGHT FIXTURE ABOVE LIGHT POLE. ROUTE CABLE WITHIN INTERSTITIAL SPACE (1) 1-1/4" UNDERGROUND CONDUIT 10 11 9
