A reinforced concrete wall corner features an offset return leg. The thickened wall section is reinforced with four number six vertical bars, while the return leg contains two number six vertical bars. Additional vertical reinforcement is sized per plan and spaced typically throughout the assembly. Number three ties are provided at six inches on center, enclosed by custom U-mesh and custom corner mesh configurations.
3 1/2" 1' 3/4" 1'-2" 1' 2' 9 1/4" 8 1/2" CUSTOM CORNER MESH, TYP. 8" 14" 21" 8" #3 TIES AT 6" O.C. U-MESH (4) #6 VERT. BARS IN RETURN LEG (2) #6 VERT. BARS IN THICKENED WALL 10" VERT. REINF. PER PLAN TYP. CUSTOM U-MESH 8" 9" 8"
