A ten-foot pole supports a dome camera attached via a wall pendant bracket, back box, and pole mount bracket. A media converter housed in a NEMA 4 enclosure is mounted directly to the pole assembly. Flexible sealtight conduit connects to the enclosure for cable management and weather protection.
SEALTIGHT CONDUIT MEDIA CONVERTER IN NEMA 4 ENCLOSURE SEALTIGHT CONDUIT MEDIA CONVERTER IN NEMA 4 ENCLOSURE 10' DOME CAMERA WALL PENDANT BRACKET BACK BOX AND POLE MOUNT BRACKET
