Surface reinforcing for a concrete wall panel features a P-2 embed plate. Four number four vertical reinforcing bars or vertical panel reinforcing are tied into the wall. Two number four U-bars are provided at each HSA row to anchor the embed plate into the concrete core.
10 SURFACE REINFORCING SCALE: 3/4"=1'-0" (4) #4 VERT. BAR OR VERT. PANEL REINFORCING (2) #4 U-BARS AT EACH HSA ROW WALL PANEL P-2 EMBED
