Category cables route through a conduit stubbed above the finished ceiling with protective bushings on both ends into a single-gang back box. A raised single-gang cover matches the architectural finish. A single-gang faceplate carries RJ45 jacks with label locations and category cable terminations. Unused ports receive blank inserts per installation notes.
CONDUIT STUBBED ABOVE FINISHED CEILING WITH BUSHINGS ON BOTH ENDS. INSTALL BLANKS ON ALL UNUSED PORTS. 1. CABLE FROM TDR RJ45 JACK. SEE PLAN FOR # OF JACKS TO BE TERMINATED LABEL LOCATION LABEL LOCATION SINGLE-GANG FACEPLATE RAISED PER ARCHITECTURAL FINISH SINGLE GANG COVER BACK BOX NOTE: CATEGORY CABLE
