A bonding conductor connects a two-lug bonding clip on the conduit to a telecommunications grounding busbar mounted via a grounding lug at ninety-six inches above finished floor. A construction channel secures to the wall plywood on the telecom room side, while a conduit strap fastens each conduit penetrating the partition. The wall separates the user space from the telecommunications room.
WALL PLYWOOD TGB GROUNDING LUG AT 96" AFF BONDING CONDUCTOR CONDUIT STRAP (TYP FOR EACH CONDUIT) CONSTRUCTION CHANNEL TECHNOLOGY ROOM GROUNDING DETAIL "A" USER SPACE TELECOM ROOM TWO LUG BONDING CLIP CONDUIT TO USER SPACE
