Nutrient tote 78-TK-515-02 connects via a suction line to nutrient feed pump 78-OCU-515-02. The discharge line runs through check valve V-78-500-06 and valve V-78-500-07. A water supply line referenced by drawing A 017-I-01-8002 ties into the system.
A 017-I-01-8002 NO. 1, NO. 2, AND NO. 3 WATER V-78-500-06 V-78-500-07 78-TK-515-02 NUTRIENT TOTE NO. 2 78-OCU-515-02 NUTRIENT FEED PUMP NO. 2
