Typical steel deck support at column detail showing structural steel angles sized as three by three by one-quarter inches provided where required to support steel deck around the column flange and web. The angles are connected with a typical three-sixteenths inch fillet weld. The assembly frames steel deck into the structural column grid.
TYPICAL STEEL DECK SUPPORT AT COLUMN DETAIL 11 TYPICAL L3x3x1/4 PROVIDE ANGLES WHERE REQUIRED TO SUPPORT STEEL DECK TYP. 3/16 TSD206
