Category 6 cabling runs from the main distribution frame or designated intermediate distribution frame to a telecommunications outlet housed in a surface-mount adapter and a four-square electrical back box. A three-quarter-inch conduit extends from the junction box to the accessible ceiling space as required. Section 27 2000 provides the telecommunications outlet and appropriately sized patch cables.
CAT6 CABLING TO THE MDF/DESIGNATED IDF CAMERA SPECIFIC SURFACE MOUNT ADAPTER 4S ELECTRICAL BACK BOX 1 PROVIDE (1) 3/4" CONDUIT FROM THE JUNCTION BOX TO THE ACCESSIBLE CEILING SPACE AS REQUIRED. 1 GENERAL NOTES FOR CLARITY, CONDUITS ARE NOT SHOWN, EXCEPT WHERE NOTED. SEE FLOOR PLANS FOR CONDUIT REQUIREMENTS. SECTION 27 2000 SHALL PROVIDE THE TELECOMMUNICATIONS OUTLET AND THE PATCH CABLES (SIZED TO FIT). 1. 2. CONSTRUCTION NOTES TELECOMMUNICATIONS OUTLET
