An F1000 VE Unistrut channel is mounted to the wall and secured with stainless steel hardware. F1119 PE Unistrut pipe supports clamp around the conduits and are fastened to the Unistrut channel using 1/2-inch by 3/4-inch 304 stainless steel hex head bolts. All associated hardware is stainless steel.
STAINLESS STEEL HARDWARE F1000 VE UNISTRUT F1119 PE UNISTRUT PIPE SUPPORT HEX HEAD BOLTS 304 S.S. 1/2"x3/4" CONDUIT SEE DETAIL 7/S-710 FOR DETAILED
