Wiring and conduit routing for an automated door operator mounted at a single door. Conduits extend from the door operator unit located just above the finished ceiling to junction boxes and wall-mounted devices near the finished floor. Numbered callouts indicate specific pathway and wiring connections routed through the ceiling space.
J 2 3 1 7 8 8 16 17 FINISHED FLOOR FINISHED CEILING NONE 4 SINGLE DOOR - DOOR OPERATOR ONLY (S4)
