Cables route from the intermediate distribution frame through a conduit stubbed above the finished ceiling with bushings on both ends into a four-inch by four-inch by two-and-one-eighth-inch deep junction box. A four-inch by four-inch raised single-gang cover matches the architectural finish. A single-gang sloped faceplate with modular openings is flush-mounted to the cover and holds modular connectors with designated label locations. All unused ports require blank inserts per project notes.
CONDUIT STUBBED ABOVE FINISHED CEILING WITH BUSHINGS ON BOTH ENDS. NOTE: 1. INSTALL BLANKS ON ALL UNUSED PORTS. CABLE TO IDF MODULAR CONNECTOR MODULAR CONNECTOR LABEL LOCATION LABEL LOCATION SINGLE-GANG SLOPED FACEPLATE WITH MODULAR OPENINGS FLUSH MOUNTED 4"x4" RAISED PER ARCHITECTURAL FINISH SINGLE GANG COVER 4"x4"x2-1/8" DEEP BOX
