Two perpendicular cable runways intersect and connect using a junction splice kit. A number 6 grounding wire bridges the joint with mechanical fasteners secured to each runway section.
CABLE RUNWAY (TYP) JUNCTION SPLICE KIT CABLE RUNWAY (TYP) #6 GROUNDING WIRE NONE 2 JUNCTION SPLICE
