A typical low voltage system control panel with a maximum weight of 75 pounds is secured to steel framing. The panel is attached at each corner using number 14 by 2-inch Hilti Kwik Pro SDS screws with washers at each manufacturer mounting hole. Additional backing is provided as specified in detail 3/SF5.40.
A DETAIL "A" STEEL FRAMING TYPICAL LOW VOLTAGE SYSTEM CONTROL PANEL. (MAX WEIGHT 75 LBS) PROVIDE BACKING PER DETAIL 3/SF5.40 #14 x 2" AT EACH CORNER , HILTI KWIK PRO SDS" (ICC ESR-2196) W/ WASHER AT EACH MANUFACTURE MOUNTING HOLE REFER TO DETAILS 2-4/TY-6.04 (TYPICAL 4 PLACES)
