CAT6 cabling runs to the main distribution frame or designated intermediate distribution frame through a three-quarter-inch conduit extending from the junction box to the accessible ceiling space. The camera mounts to a surface mount adapter attached to a 4S electrical back box on plywood or another approved mounting surface. General notes require conduits to be omitted for clarity except where explicitly noted, with requirements referenced on the floor plans. Section 27 2000 provides the telecommunications outlet and sized patch cables.
PLYWOOD OR OTHER SURFACE CAT6 CABLING TO THE MDF/DESIGNATED IDF CAMERA-SPECIFIC SURFACE MOUNT ADAPTER 4S ELECTRICAL BACK BOX 1 PROVIDE (1) 3/4" CONDUIT FROM THE JUNCTION BOX TO THE ACCESSIBLE CEILING SPACE AS REQUIRED. 1 GENERAL NOTES FOR CLARITY, CONDUITS ARE NOT SHOWN, EXCEPT WHERE NOTED. SEE FLOOR PLANS FOR CONDUIT REQUIREMENTS. SECTION 27 2000 SHALL PROVIDE THE TELECOMMUNICATIONS OUTLET AND THE PATCH CABLES (SIZED TO FIT). 1. 2. CONSTRUCTION NOTES TELECOMMUNICATIONS OUTLET
