A wall angle support kit is anchored to a three-quarter-inch fire-rated A/C grade void-free plywood wall partition. Hex lag screws with typical split lock washers secure the structural support angles to the substrate. Cable tray components are fastened into the assembly using standard threaded hardware.
SPLIT LOCK WASHER DRYWALL 1. 3/4" FIRE RATED, A/C GRAD, VOID FREE PLYWOOD. 2. WALL ANGLE SUPPORT KIT. 3. HEX LAG SCREW (TYP). NOTES: 2 3 2 1 NONE 5 WALL ANGLE SUPPORT
