A telecommunications optical line terminal connection configuration features an open door across a width of nineteen inches. Three 1:32 splitters connect to the optical line terminal ports, serving sixteen typical configurations. Suite optical network terminal risers accommodate ninety-six strands across twelve numbered ports.
19.0 1 2 3 4 5 6 7 8 9 10 11 12 OLT CONNECTION TO 1:32 SPLITTER (3) 1:32 SPLITTER SUITE ONT RISERS 96 STRANDS (16) TYPICAL CONFIGURATIONS FRONT VIEW (WITH DOOR OPEN)
