A vertical wall bracket system utilizes CPI model 10608-701 or equal for equipment mounting. For attachment to concrete masonry units, the assembly secures through plywood using two one-half-inch Hilti KB TZ stainless steel expansion anchors with a three-and-five-eighths-inch minimum embedment. Installation complies with ICC-ES-3785 standards. Spacing requires a maximum of eighteen inches on center from the bottom of the floor or top of the ceiling, and a maximum of twenty-four inches on center apart from each adjacent bracket.
CPI# 10608-701 OR EQUAL. FOR ATTACHMENT TO CMU, USE (2)1/2" HILTI KB TZ (STAINLESS STEEL) EXPANSION ANCHORS THROUGH PLYWOOD INTO CMU WITH 3-5/8" MINIMUM EMBED. INSTALL PER ICC-ES-3785. INSTALL MAX. 18" O.C. FROM BOTTOM OF FLOOR OR TOP OF CEILING. MAX. 24" O.C. APART FROM EACH BRACKET OTHERWISE.
