An interior IP camera is mounted to a wall at ninety-six inches above the finished floor. The unit connects to a junction box equipped with a single-gang device ring. A one-inch conduit runs upward from the junction box through the wall assembly toward the accessible ceiling.
WALL FINISHED CEILING FINISHED FLOOR 96" AFF 1. JUNCTION BOX WITH SINGLE GANG DEVICE RING. 2. 1" CONDUIT TO ACCESSIBLE CELIING. NOTES: 1 2 NONE 7 INTERIOR IP CAMERA (WALL MOUNTED)
