An in-wall junction box is installed within a drywall partition or column and connects to a one-and-a-quarter-inch conduit stub-up. The conduit routes upward through the wall cavity and extends horizontally above the inaccessible ceiling to the nearest accessible ceiling or runs directly as a homerun to the telecom distribution rack. The system is bounded vertically by the lower structural slab and the upper concrete slab.
STRUCTURAL SLAB INACCESSIBLE CEILING SLAB IN WALL JUNCTION BOX 1-1/4" CONDUIT STUB UP IN DRYWALL OR COLUMN CONDUIT TO NEAREST ACCESSIBLE CEILING OR HOMERUN TO TDR
