A wall angle support kit mounts a cable tray or rack to a framed wall assembly. The backing consists of three-quarter-inch fire-rated A/C grade void-free plywood surfaced with drywall. Steel angle sections anchor to the wall using typical hex lag screws fitted with split lock washers. J-bolts secure the tray framing components to the support angles.
DRYWALL WALL ANGLE SUPPORT KIT WALL ANGLE SUPPORT KIT SPLIT LOCK WASHER HEX LAG SCREW (TYPICAL) 3/4" FIRE RATED A/C GRADE, VOID FREE PLYWOOD
