A surface-mounted data outlet featuring a CAT6 jack and a blank insert connects via a CAT6 patch cable to a ceiling-mounted device such as a wireless access point or PoE camera. A communications cabling J-hook is mounted to the wall or ceiling within the above-ceiling space to support the cable run. A three-foot cable slack loop is provided at the outlet location.
SURFACE MOUNTED DATA OUTLET INSERT CAT6 JACK PROVIDE 3 FEET CABLE SLACK LOOP AT OUTLET LOCATION. COMMUNICATIONS CABLING J-HOOK. WALL OR CEILING MOUNTED ABOVE CAT.6 PATCH CABLE CONNECT TO CEILING MOUNTED DEVICE (WAP, CEILING SPACE POE CAMERA) BLANK CEILING
