Communication raceway devices are shown with three mounting configurations including above-ceiling mounted, flush-ceiling mounted, and wall mounted assemblies. The above-ceiling detail positions the raceway box eight inches above an accessible ceiling. The flush-ceiling mounted detail integrates the device with a hard ceiling. The wall-mounted detail secures the device flush against a vertical partition.
4 1 2 SYMBOLS: R.01 CEILING 3 COMM RACEWAY DEVICES WALL MOUNTED 4 1 2 HARD CEILING 3 5 4 1 ACCESSIBLE CEILING 3 5 8" ABOVE CEILING MOUNTED FLUSH CEILING MOUNTED X X
