Structural · S-ZYXV9

Typical Shear Stud Detail

Materials

Timber / Wood

Connections

Shear Stud / Composite

About this detail

All typical shear studs shall be three-quarter inch diameter. A one-inch clearance is maintained at the edge condition.

TYPICAL ALL SHEAR STUDS SHALL BE 3/4"ø SHEAR STUD DETAIL CLR. 1"

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
