Geometric layout for a steel stair channel stringer and its associated nosing line. A working point marks the intersection for structural alignment, located eleven and one-half inches from the support edge. The channel stringer and its attachment to the primary structure are provided by others as noted on the drawing.
11 1/2" NOSING LINE CHANNEL STRINGER NOTE: CHANNEL STRINGER & ATTACHMENT TO STRUCTURAL BY OTHERS WP
