An eight-inch concrete masonry unit wall detail shows a lintel block reinforced with one number six bar bent at one hundred eighty degrees for openings up to four feet unless noted otherwise. Vertical and horizontal wall reinforcement is detailed within the grouted cells. Similar reinforcing details apply at the window sill.
LINTEL SECTION A-A AT 8" C.M.U. WALL LINTEL BLOCK 180° BENT 1-#6 FOR OPENINGS ≤ 4'-0" U.N.O. WALL REINF. NOTE: SIM. @ SILL
