Structural · S-ZT6M3

Brace and Hanger Connection to Metal Deck

Materials

Metal (misc.)

Elements

Decks Bracing

Connections

Bracing Connection Timber / Mass-Timber Connection

About this detail

A diagonal brace or vertical hanger connects to an overhead metal deck utilizing a TSN Stiff Clip LS, Simpson MSJC10.25, or an L1-1/2x3x97 MILS light-gauge angle. The clip is fastened to the metal deck using number 10 sheet metal screws, spaced with specific edge distances and minimum low flute requirements. Two orientations are detailed: one with the clip perpendicular to the deck flutes spanning a minimum of four low flutes, and one parallel to the flutes spanning a length of one foot three inches. The brace or hanger member attaches to the clip using three number 10 sheet metal screws, unless noted otherwise.
