A cross-laminated timber panel joint is secured with a CMST12 metal strap and 0.162 inch by 2-1/2 inch nails. The strap requires a thirty-three inch minimum end length with thirty-seven fasteners, and an eighteen inch minimum lap splice length with eighteen fasteners. Fasteners and strap placement are installed per plan.
CLT PANEL JOINT END LENGTH LAP SPLICE STRAP TABLE STRAP CMST12 FASTENERS 0.162 x 2-1/2" NAILS END LENGTH 33" MIN # OF FASTENERS IN END LENGTH (37) LAP SPLICE LENGTH 18" MIN # OF FASTENERS IN LAP SPLICE (18) STRAP PER PLAN
