Beams running continuously over a column tenon are secured with one half-inch diameter through-bolt passing through each beam pair and the column tenon. Additional connection is provided by angled screws per sheet S-505 below, with specific narrow and wide dimensional tolerances where the beams meet over the column.
COLUMN TENON REMAINING BETWEEN BEAMS BEAMS RUNNING OVER COLUMN (1) 1/2"Ø THRU BOLT THRU EACH BEAM PAIR AND COL TENON PLAN WIDE DIM NARROW DIM 5 1/2" 5 3/8" WHERE BEAMS MEET OVER COL 2" ANGLED SCREW PER BELOW / 5 S-505 MIN 3 1/4"
