A continuous 4x4x1/4-inch steel angle provides deck support parallel to a concrete masonry unit wall, anchored by a continuous 1/4x3-inch plate fastened to a Fero clip with break-away fasteners spaced at four feet on center. The metal deck bears on the continuous plate and is welded directly to it rather than the supporting angle, with deck connections detailed per general structural notes.
WELD METAL DECK TO CONT PL ONLY (NOT ANGLE). PROVIDE DECK CONNECTION PER GENERAL NOTES T/DECK PER PLAN METAL DECK PER PLAN, ORIENTATION VARIES CONT L4x4x1/4 FERO BREAK- AWAY CONTINUOUS ANGLE FOR DECK SUPPORT. CONNECT TO CMU WALL PER CONT 1/4x3" PL, FASTEN TO FERO CLIP WITH BREAK-AWAY FASTENERS AT 4'-0" OC 7/S8.102 CMU WALL & REINF PER PLAN
