A painted tilt-up concrete monolithic panel meets a concrete slab-on-grade at the building perimeter. The slab is underlaid by a drainage course and extruded-polystyrene board insulation with an R-10 thermal rating. Exterior finished grade slopes away from the building per civil engineering requirements.
CONCRETE SLAB-ON-GRADE EXTRUDED-POLYSTYRENE BOARD INSULATION (R-10) TILT-UP CONCRETE MONOLITHIC PANEL, PAINTED DRAINAGE COURSE FINISHED GRADE. SLOPE AWAY FROM BUILDING, TYP. RE: CIVIL GRID
