This isometric detail shows the edge profile of a swimming pool with a concrete deck and wall finished in white plaster. The deck features a 3/4-inch form recess for depth marker and caution marker plaque tiles, alongside 15M Daltile D195 non-slip ceramic tiles. The pool wall incorporates 6-inch by 6-inch water level tiles, 2.5-inch by 6-inch bullnose tiles, and a black double bullnose edge. A stainless steel gutter cap, EKO3 model DP-108-00004, is centered at all rope anchor and wall plate locations. Additional details include 1-inch by 1-inch non-glazed ceramic mosaic targets and 4.25-inch by 4.25-inch black on blue ceramic tile depth markers flush with the finish.
16'' 14'' 12'' 12'' FOR DEPTH MARKER/ FORM RECESS ['' DEEP CAUTION MARKER PLAQUE 12'' TILES. 12'' WHITE PLASTER BULLNOSE TARGET @ < OF TILE FLUSH W/ BLACK DOUBLE EA. RACING LANE 1''x 1'' NON-GLAZED CERAMIC MOSAIC PLASTER FINISH 12'' FINISH 14'' TARGETS WATER LEVEL 6''x 6'' W.L. TILE ['' RAD @ DECK 1''x 1'' NON-GLAZED 4|''x 4|'' BLACK ON BLUE CERAMIC TILE DEPTH MARKERS CERAMIC MOSAIC 2\''x 6'' BULLNOSE 4|'' TYP. 8\'' FLUSH ROPE ANCHOR < 4'' 15 M TILE 'DALTILE' D195 'OAK MOSS' WITH NON-SLIP SURFACE ON DECK. EKO 3 #DP-108-00004 STAINLESS STEEL GUTTER CAP CENTERED AT ALL RA & WP RA LOCATIONS TYP.
