A wide-flange beam frames into a wide-flange girder web using a typical shear plate connection with slip-critical bolts. The top flange of the supported beam features a complete joint penetration weld at the top and bottom typically. Plan symbols illustrate the beam framing condition relative to the supporting member.
WF BM WF GIRDER CJP T&B TYP TYPICAL SHEAR PLATE CONNECTION W/ SC BOLTS, TYP SHALLOW SUPPORTED BEAM SHOWN THUS ON PLANS: OR
