An open web joist aligns with a wide flange beam sized per plan and connects through a full-depth L5x5x3/8 angle member. A 3-inch dimension governs the spacing between the joist and the supporting wide flange beam connection detail. Two-inch fillet welds of 1/4-inch size secure the connection at the top and bottom (T&B). Additional connections are referenced by detail callouts S8.10 and S8.20.
3" 1/4 2 T&B L5x5x3/8, FULL DEPTH OF TRUSS CONN PER SIM WF BEAM PER PLAN OPEN WEB JOIST PER PLAN BRIDGING ALIGNED w/ WF BEAM PER SIM 12 S8.20 3 S8.10
