Structural · S-ZNEBZ

Elevator Rail Connection at Roof

Materials

Steel

Elements

Columns Beams Walls Roofs Decks Bracing Connections / Plates

Connections

HSS Connection Bracing Connection Welded Connection Expansion / Slip Connection

About this detail

An elevator rail connection at the roof level features a wide-flange beam supported by a hollow structural section column, with a continuous 3/16-inch bent plate running around the elevator opening. The assembly includes an L8x4x1/2 by 1 foot 2 inch angle with two 3/4-inch diameter by 5-inch end welded studs at 10 inches on center, welded with a 1/4-inch fillet weld on three sides. A brace member frames in using L6x3-1/2x3/8 by 1-foot angles on each side with a 13/16 by 1-1/2 inch slotted hole and one 3/4-inch diameter machine bolt hand tightened. A supplemental partial detail shows a 1-inch minimum gap above the hollow structural section column and angles connected with through-bolts.
