Metal deck bears on an edge member and connects with five-eighths-inch diameter puddle welds sized per structural notes. An edge closure of the same gauge as the deck is fastened to the edge member using number ten screws spaced at four inches on center. The deck flutes and edge closure are secured at the support interface.
EXTERIOR BEARING PARALLEL EDGE / EDGE CLOSURE 5/8" Ø PUDDLE WELDS SEE NOTES 5/8" Ø PUDDLE WELDS SEE STRUCTURAL NOTES EDGE CLOSURE SAME GAUGE AS DECK No 10 SCREWS @4"OC EDGE MEMBER EDGE MEMBER
