A hollow structural section column supports a steel beam and a three-eighths-inch bent cap plate below a cold-formed steel wall and steel post parapet assembly. A metal deck bears adjacent to the column, and structural members are connected with bolted framing angles and welds including a three-sixteenths-inch fillet weld. Additional details and callouts for the steel post and architectural integration are coordinated per architectural drawings.
3/16 BENT CAP 3/8" MTL DECK SEE ARCH. STL POST - FOR DETAILS & CALLOUTS IN COMMON SEE C.F.S. WALL STL BM 1 1 5 /8" STL BM HSS COL. PARAPET 8 S5.12
