A concrete slab bears upon a structural steel beam with deck supports detailed per typical standards. Diaphragm reinforcement and slab thickness are sized per plan. Slab reinforcement matches the size and spacing of the adjacent SOMD members. The steel beam flange ties into adjacent concrete construction with headed stud anchors.
2 Lsb, TYP DECK SUPT PER TYP DETAILS DIAPHRAGM REINF PER PLAN DECK SUPT PER TYP DETAILS BU SLAB PER PLAN PLAN PER EL 101' - 8" Lsb MATCH SOMD REINF SIZE & SPCG
