The assembly consists of a 3/16 inch thick A36 steel plate secured to a concrete substrate using a 1/2 inch diameter Hilti KB-TZ2 anchor with a 2-1/2 inch effective embedment. A structural steel component is welded or connected to the plate, positioned at a specified coordinate angle with the bed base. The drawing indicates the positioning and anchoring specifications for structural steel connections to concrete.
Text on the drawing
1/2' DIA HILTI KB TZ2 W/ 2 1/2" EFFECTIVE EMBED (ESR - 4266) 3/16" THK A36 PL COORDINATE ANGLE W/ BED BASE B DETAIL A 50.75"
