Framing configuration for an opening in a non-bearing cold-formed steel stud wall. The assembly consists of minimum 18-gauge steel tracks at the top and bottom, fastened with number 12 self-tapping metal screws spaced at six inches on center typical. Two minimum 18-gauge steel studs are positioned to form the header or sill condition, secured with number 12 self-tapping metal screws at six inches on center on each side. Infill steel studs are sized per plan or framing elevation and tied into the track assembly.
18GA MIN STEEL TRACK T&B (2)-6"x18GA MIN STEEL STUDS #12 SMS @ 6"OC EA SIDE #12 SMS @ 6"OC, TYP STEEL STUD PER PLAN OR FRAMING ELEV SECTION A-A
