Concrete reinforcing layout at a wall thickness transition where the offset exceeds six inches. Vertical reinforcing dowels extend from the level below, matched in size and spacing to the reinforcement above, with hooked vertical bars terminating at the top of the wall. A number four tie matches the vertical reinforcing spacing at the slab location. The offset detail requires a one and one-half inch minimum and four inch maximum dimension.
#4 TIE TO MATCH VEF SPACING SLAB WHERE OCCURS HOOK VERT AT TOP OF WALL DWL TO MATCH VERT REINF SIZE & SPCG ABOVE, EXTD TO LEVEL BELOW DOWEL TO MATCH VERT REINF SIZE & SPCG ABOVE NOTE 1 OFFSET 1 1/2" MIN 4" MAX OFFSET > 6" NOTES: 1. SEE THE SHEAR WALL REINFORCEMENT NOTES FOR LAP LENGTH. 2. SEE PLAN AND WALL ELEVATIONS FOR ADDITIONAL INFORMATION. 27 1/2" 5 3/8" 12" 7 TYPICAL REINFORCEMENT AT WALL THICKNESS CHANGE
