Edge conditions occur at a structural steel column for both parallel and perpendicular web orientations relative to the slab edge. An L2x2x3/16 angle is positioned at each flange with an edge form installed per Table K.1. The closure plate is held back up to a half-inch maximum to clear welds, with fillet welds specified at the connections.
L2x2x3/16 ES EDGE FORM PER "TABLE K.1", 3/16" MIN SLAB EDGE EDGE FORM PER "TABLE K.1" L2x2x3/16 AT EA FLG TYPICAL EDGE CONDITION AT COLUMN COLUMN WITH WEB PARALLEL COLUMN WITH WEB PERPENDICULAR SLAB EDGE SEE NOTE 6 1/2" HOLD CLOSURE PL BACK TO CLEAR WELD (1/2" MAX), TYP 1/2" TYP
