A buckling-restrained brace connects to a steel column and steel beam through a gusset plate sized per the brace requirements. Stiffener plates are provided on the near side and far side of both the column and the beam as required by the manufacturer. The gusset plate and beam connection are field or shop welded using specified weld sizes and lengths. A work point is established at the intersection of the framing centerlines. The steel column and steel beam sizes are determined per plan.
CP TYP AT FLANGES STIFF PL NS & FS AS REQ'D BY COREBRACE TYP COREBRACE BRB, TYP Wc Lwc Wc Lwc Wb Lwb Wb Lwb GUSSET THICKNESS, tg STIFF PL NS & FS AS REQ'D BY COREBRACE, TYP STL BM SEE PLAN WORK POINT STL COL SEE PLAN Lgb Lgc M
