A depressed cast-in-place concrete floor box opening is formed within a slab-on-grade, featuring continuous number five reinforcing bars at the mid-height of the wall with standard ninety-degree hooks. The floor box matches the slab thickness plus a maximum one-foot depth, with slab reinforcement matching the main slab design. Architectural access floor tile and associated assemblies sit flush at the top surface.
1 S-155022 S-155022 3 AS REQUIRED - SEE ARCH. ACCESS FLOOR TILE AS REQUIRED - SEE ARCH. STD. 90º HOOK, TYP. #5 CONT. AT MID-HEIGHT OF WALL, TYP. MATCH S.O.G. REINF. MAX. 1' - 0" 6" SEE 6" MATCH SLAB THICKNESS SEE FOR REINF. 1 S-155022
