Concrete walls feature horizontal reinforcing bars matched by bent corner bars detailing typical lap lengths at wall corners and intersections. Additional vertical reinforcing bars are placed at both corners and wall intersections. The horizontal wall bars lap around the corners to maintain structural continuity.
ADDITIONAL VERT BARS AT CORNER TYP CORNER BARS TO MATCH WALL HORIZ BARS CONC WALL CORNER BARS TO MATCH WALL HORIZ BARS CONC WALL ADDITIONAL VERT BARS AT INTERSECTION TYP LAP LENGTH, TYP LAP LENGTH, TYP
