Perimeter steel deck details show support conditions for both parallel and perpendicular deck orientations relative to the edge beam. The parallel configuration features a twelve gauge continuous bent plate welded to the beam top flange, secured with three-quarter-inch diameter studs at twelve inches on center with maximum overhangs up to two feet. An alternate parallel condition incorporates an L4x4x1/4 angle spaced at eight feet maximum per detail 9D. The perpendicular condition uses a sixteen gauge continuous bent edge plate supporting the fluted steel deck spanning across the edge beam.
STEEL DECK PERPENDICULAR TO EDGE BM STEEL DECK PARALLEL TO EDGE BM 16 GA BENT EDGE PL CONT STEEL DECK SEE PLAN STEEL DECK SEE PLAN 12 GA CONT BENT PL (WELDED TO BEAM) 8" MAX 2'-0" MAX 3/4"Ø @12" OC STEEL DECK SEE PLAN 12 GA CONT BENT PL (WELDED TO BEAM) 2'-0" MAX L4x4x1/4 @ 8'-0" MAX PER DETAIL 9D/- 3/4"Ø @12" OC (0'-8" MAX) A (2'-0" MAX) B 2" TYP
