A twenty-eight by thirty-six inch reinforced concrete column features longitudinal steel bars enclosed by ties with alternating hooks. A one-and-a-half-inch concrete clearance is maintained to the ties typically throughout the cross-section. The column is aligned with a structural grid line.
C7 28"x36" COLUMN 1½" CLR. TO TIES - TYP. 36" 1 1/2" GRID TIES - ALT. HOOKS TYP.
