A hollow structural section canopy member connects to a concrete wall using a half-inch by nine-inch by ten-inch plate embedded with four three-quarter-inch diameter by six-inch long stud bolts at six-inch gauge. All welded edges are ground smooth and prepared for prime and paint finish. Canopy finishes are coordinated per architectural specifications.
4" 4" 1/4 HSS SEE PLAN PL 1/2"x9"x10" W/ (4) 3/4"Ø x 6" LONG STUD BOLTS @ 6" GA. GRIND ALL WELDED EDGES SMOOTH READY FOR PRIME & PAINT CANOPY FINISH SEE ARCH TYP
