A hollow structural section column frames against a steel tank utilizing a three-eighths-inch by four-inch by nine-inch plate connected with through bolts. A complete joint penetration weld ties the steel components together at the connection interface. The adjacent steel beam aligns with the column per elevation and reference details.
C.J.P. COL. REF. ELEVATION TANK BY OTHERS W.P. PL3/8x4x0'-9" w/ THRU BOLTS REF. 10/S6.06 PLATE AND CONNECTION BY OTHERS BEAM REF. ELEVATION TYP. PLAN DETAIL NOTE: REF. DETAIL 15/S6.06 FOR ADDITIONAL INFORMATION NOT SHOWN.
